Engine Weima WM170F-Q – engine-reliable, modern and versatile!
Weima WM170F-Q is a four-stroke petrol engine with single-cylinder and air-cooling system. This engine has 7 HP and consumes 395 g / kWh of fuel. Thanks to its 3.6 liters tank, it can work constantly for about 2 hours without refueling.
New engine Weima WM170F-Q is easy to maintain and it is very reliable in use. WM170F-Q has a low level of noise and smoke emissions, and you can easily run it under any weather conditions. Application range suits for both industrial and domestic sectors. This model can be installed on different house and agricultural machines. Weima WM170F-Q is often used as a spare engine for various beam mowers, tillers, vibration plates, mini dump trucks, water pumps, generators, and many other gasoline-powered devices.
The crankshaft is standardized. Weima WM170F-Q can be used as a spare engine on machines with the same size of the crankshaft. The shaft of this engine has a direct sunk key output.
Our engines are not only reliable, but also environmentally friendly! They fulfil all requirements of the emission standards in accordance with Euro 5.
- Reliable and environmentally friendly engine (Euro 5 certified)
- Cylinder with a working volume of 212 cm3 with a cast iron and an aluminum block with large cooling fins guarantees a reliability and long service life
- Depending on the modification, there are presented high-performance filter with an oil bath (for example, “cyclone”) and a fine / coarse filter of the automobile type. For normal working conditions, a “dry” version is sufficient
- To facilitate maintenance in this model there are two oil filling mouths
- 19.05 mm diameter shaft with sunk key output
- Rotation occurs counterclockwise when it is evaluated from the shaft side
- GTIN: 6971472300902
- Type: 4 stroke, single cylinder, forced air cooling, OHV
- Displacement: 212 cm³
- Bore × Stroke: 70 × 54 mm
- Max. power: 5.1 kW / 7 HP / 3600 rpm
- Rated power: 5 kW / 3600 rpm
- Max. torque: 12.5 N∙m / 2500 rpm
- Shaft diameter: 19.05 mm (sunk key)
- Fuel tank /engine oil capacity: 3.6 / 0.6 L
- Minimum fuel consumption: 395 g/kW∙h
- Starting system: Recoil starter
- Dimensions: 390 × 330 × 330 mm
- Net weight: 16 kg
- Petrol engine Weima WM170F-Q
- 1 × Set of keys
- 1 × Owner’s manual
